Description
TECHNICAL SPECIFICATIONS
| Working Size | 1300x2500x170mm | |||
| Feed Height | 150mm | |||
| Spindle Power | Air-cooled 3.0kw, 40000rpm spindle | |||
| Spindle Speed | 0~40000rpm | |||
| Tool Diameter | Φ3.175, Φ4, Φ6, Φ8 | |||
| Driver | XY AC servo, Z axis 750W AC Servo, A axis 200W AC Servo | |||
| Control System | SIGNKEY dedicated CCD system | |||
| Mechanical Structure | Industrial square steel pipe | |||
| Transmission System | Ball screw for Z; X,Y-Grinding helical rack + planetary reducer | |||
| XYZ Rails | Linear guide | |||
| Repositioning Accuracy | <0.03mm/300mm | |||
| Max No-loaded Speed | 90m/min | |||
| File Transfer | USB | |||
| File Format | HPGL or standard G code | |||
| Power | AC220V or 380V,50-60Hz | |||
| Working Platform | Vacuum adsorption platform with fixture slot | |||
| Vacuum Pump | 7.5kw air-cooled vacuum pump | |||
| Dust Collection System | High-Power Intelligent Vacuum System | |||
| Machine Dimensions | 2000*3100*1650mm | |||
| Packaging Dimensions | 2150*3250*2000mm | |||
