Description
Dimension
3060mm(L) x 2350mm(W) x 1650mm(H)
Table Size
2630mm(L) x 1440mm(W)
Weight
1200kg
Cutting Width
1300mm x 2500mm x 180mm
Max Material Height
N1(180mm) / N3(200mm)
Spindle Power
N1(3hp), N3(5.5hp), +Water Cooling
Speed RPM
0-24,000rpm
Max Speed
20,000mm/min
Mark Recognition
CCD Camera
Tool Diameter
Ø3.175, Ø4, Ø6, Ø8, Ø12.7
Driver
Hybrid Servo
OTT Drive
+Leadshine AC Servo
Repositioning Accuracy
< 0.03mm/300mm
Mechanical Structure
Industrial Square Steel Pipe
Transmission
Z Ball Screw, XY Pulley & Gear Rack
Table Top
PVC and Aluminum Alloy
Dust Collector
High Volume Vacuum
Control Software
WEIHONG + CCD
File Format
HPGL / Standard G-Code
Data Interface
USB 2.0
Input Voltage
AC-220V/380V, 50-60Hz
