Description
Model
IP1801/02 UI
Print Head
1~2 Epson i3200 U1 print heads
Boards & RIP Software
Hoson Board & PhotoPrint UV RIP Software
Ink
Hapond UV Ink
Colors
CMYK + White
Ink Supply System
Bulk ink system with 1.5L main ink tank
Printing Width
Max. 1800mm
Printing Media
Banner, Coated PP, Vinyl, PVC Film…
Y-Axis
20mm Diameter
Printing Bed
144mm Wide printing bed
Suction System
Adjustable Vacuum Suction System
Heating System
Rear-pritng bed-front 3 heater
Print Speed
Mode
4PASS
6PASS
8PASS
4PASS
6PASS
8PASS
Resolution
720×1200
720×1800
720×240
720×1200
720×1800
720×240
1 P.H.
12²/h
8m²/h
6m²/h
12²/h
8m²/h
6m²/h
2 P.H.
24m²/h
16m²/h
12m²/h
24m²/h
16m²/h
12m²/h
Drying System
LED CUring System
Working Environment
Temp. 20℃~28℃, Humidity: 25%~65%
Printer Packing
Wooden Box
Input Voltage
AC220 50/60Hz
Packed / Installed Size (LxWxH mm)
3400x570x650 / 2785x670x1300
Gross Weight/ Net Weight (kg)
295 / 202
