Description
Dimension
4780mm(L) x 2600mm(W) x 1500mm(H)
Weight
1200kg
Max. Print Width
2440mm x 1220mm
Max. Media Width
2440mm x 1220mm
Ink Type
UV Curable Ink
Ink Color
CMYK+W, Optional: LC LM
Print Head
KONICA 1024i(6pl/13pl), Optional: KONICA 1024A
No. of Print Head
5 – 12 units
Print Resolution
480x1080dpi, 480x1440dpi, 540x1080dpi, 540x1440dpi
Print Speed (m2/hr)
Production
Quality
High Precision
Quality
High Precision
4.PH
32
23
16
32
23
16
8.PH
63
46
33
63
46
33
Print Mode
Uni- and Bi- Direction
Media Type
Acrylic, Aluminium, Ceramic Tiles, Corrugated Board, Foam Board, Glass, Metal Plate, Back-lit, Banner Flex, Canvas, Mesh Paper, Synthetic Paper, Reflective Film, Sticker, Tarpaulin, Textile, Non-Woven, Wallcoverings, etc.
Software
Hapond Printer Manager, Print Factory, Optional: Caldera
Curing System
LED UV System
Cleaning System
Positive Flush
Image Format
BMP, TIFF, JPEG, EPS, PDF, etc.
Colour Management
ICC Profile
Data Interface
USB 2.0/3.0
Input Voltage
Single Phase, AC220V±10% (50/60Hz), 32A
Working Environment
Temperature: 20oC-28oC
Humidity: 40%-70% RH
