Description
Model
EP1602 / EP 1802
Print Head
2 x Epson I3200 E1 print heads
Board & Rip Software
BYHX/Hoson /Sungyung & Maintop Rip Software 6.1
Ink
Eco-solvent Ink (2 years outdoor durability)
Color Config.
CMYK
Ink Supple System
Bulk ink Supply system with 1.5L Main INK tank
Print Width
Max. 1600mm / 1800mm
Media Type
Banner, Coated PP, Vinyl, PVC Film…
Main Girder Structure
160*60*3mm Square Tube
Y-Axis
20mm Diameter
Printing Bed
144mm Wide Printing Bed
Suction System
Adjustable Vacuum Suction System
Print Speed (m2/hr)
Mode
3PASS
4PASS
6PASS
3PASS
4PASS
6PASS
Resolution (DPI)
360X1800 dpi
720X1200 dpi
720X1800 dpi
360X1800 dpi
720X1200 dpi
720X1800 dpi
Weak Feather
49m²/h
36m²/h
25m²/h
49m²/h
36m²/h
25m²/h
Normal Feather
46.5m²/h
36m²/h
25m²/h
46.5m²/h
36m²/h
25m²/h
Strong Feather
38.5m²/h
30m²/h
22m²/h
38.5m²/h
30m²/h
22m²/h
Heating System
3 in 1 Heating Control Panel (Rear-Printing Bed-Front 3 Heaters)
Drying System
Rolling Fans
Printer Size
2585*670*1300 / 2785*670*1300
Printer Packing
Wooden Box
N.W/G.W.
200KG / 260KG
Packing size
2700*570*650 / 2900*670*650
