Description
Type
1013, 1815, 2516, 2518, 3020
Size (mm)
2040x2335x1290 / 2740x2235x1290 / 3440x2335x1290 / 3440x2535x1290 / 3940x2735x1290
Effective Cutting Area (mm)
1000×1300 / 1800×1500 / 2500×1600 / 2500×1800 / 3000×2000
Special Size
Customizable
Safety Device
Physical anti-collision mechanism + infrared induction anti-collision to ensure production safety
Tools
EOT, UCT, CCD, Cursor, Pen, POT, DRT, PRT, KCT
Cutting Thickness
≤50mm
Cutting Material
All kind of corrugated board, card board, composite material, acrylic, honeycomb, high impact, paper foam, PVC, etc.
Cutting Speed
Up to 1200mm/s (depends on the type of material)
Cutting Precision
≤0.1mm
Repeatability
≤0.05mm
Fixing Method
Individual section vacuum suction
Interface
Ethernet Port
Driving System
Intelligent digital control servo system
File Format
DXF, HPGL compatible format
Numerical Control Panel
Mult-Language LCD Touch Screen
Suction Power
3KW~12KW (Variable frequency air pump is optional)
Power Supply
AC 380V/220V ±10% (50/60Hz)
Working Environment
Temperature: 10oC~40oC
Humidity: 20%~80% RH
