Description
Dimension
4500mm(L) x 940mm(W) x 1430mm(H)
Weight
800kg
Max. Print Width
3200mm
Max. Media Width
3340mm
Ink Type
Solvent Based Pigment Ink
Ink Color
CMYK
Ink Supply System
Negative Pressure Recirculation System
Print Head
KONICA 512i(30pl), Optional: KONICA 1024i(13pl)
No. of Print Head
4 / 8 units
Print Resolution
480x540dpi, 480x720dpi, 480x1080dpi
Print Speed (m2/hr)
Production
Quality
High Precision
Quality
High Precision
4.PH
105
70
52
105
70
52
8.PH
210
140
105
210
140
105
Print Mode
Uni- and Bi- Direction
Media Type
Back-lit, Banner Flex, Canvas, Mesh Paper, Synthetic Paper, PVC, Reflective Film, Sticker, Tarpaulin, Textile, Wallcoverings, etc.
Software
Hapond Printer Manager, PhotoPrint
Cleaning System
Positive Flush
Drying System
Infrared Heating with Fan Drying System
Media Handling
Auto Media Release / Take Up System
Image Format
BMP, TIFF, JPEG, EPS, PDF, etc.
Colour Management
ICC Profile
Data Interface
USB 2.0 / 3.0
Input Voltage
Single Phase, AC220V±10% (50/60Hz)
Working Environment
Temperature: 20oC-28oC
Humidity: 40%-70% RH
